PERFORMANCE
|
|
Processor
|
Intel® Core™
i7-13650HX, 14C (6P + 8E) / 20T, P-core 2.6 / 4.9GHz, E-core 1.9 / 3.6GHz,
24MB
|
|
AI PC Category
|
AI-Powered
Gaming PC
|
|
Graphics
|
NVIDIA® GeForce RTX™
4060 8GB GDDR6, Boost Clock 2370MHz, TGP 115W, 233 AI TOPS
|
|
Chipset
|
Intel® HM770
Chipset
|
|
Memory
|
2x 12GB SO-DIMM
DDR5-4800
|
|
Memory Slots
|
Two DDR5
SO-DIMM slots, dual-channel capable
|
|
Max Memory
|
Up to 32GB DDR5-4800
|
|
Storage
|
512GB SSD M.2
2242 PCIe® 4.0x4 NVMe®
|
|
Storage Support
|
Up to two drives, 2x
M.2 SSD • M.2 2242 SSD up to 1TB each
|
|
Storage Slot
|
Two M.2 2280
PCIe® 4.0 x4 slots
|
|
Card Reader
|
None
|
|
Optical
|
None
|
|
Audio Chip
|
High Definition (HD)
Audio, Realtek® ALC3287 codec
|
|
Speakers
|
Stereo
speakers, 2W x2, optimized with Nahimic Audio
|
|
Camera
|
FHD 1080p with
E-shutter
|
|
Microphone
|
2x, Array
|
|
Battery
|
60Wh
|
|
Power Adapter
|
230W Slim Tip
(3-pin)
|
|
Special Features
|
AI Chip: LA1
|
|
DESIGN
|
|
Display
|
15.6" FHD
(1920x1080) IPS 300nits Anti-glare, 100% sRGB, 144Hz, G-SYNC®
|
|
Touchscreen
|
None
|
|
Color Calibration
|
None
|
|
Keyboard
|
White
Backlit, English (UK)
|
|
Touchpad
|
Buttonless Mylar®
surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm
(2.95 x 4.72 inches)
|
|
Case Color
|
Luna Grey
|
|
Surface Treatment
|
Painting
|
|
Case Material
|
PC-ABS (Top),
PC-ABS (Bottom)
|
|
Pen
|
Pen Not Supported
|
|
Dimensions (WxDxH)
|
359.86 x
258.7 x 21.9-23.9 mm (14.17 x 10.19 x 0.86-0.94 inches)
|
|
Weight
|
Starting at 2.38 kg
(5.25 lbs)
|
|
SOFTWARE
|
|
Operating System
|
None
|
|
Bundled Software
|
None
|
|
CONNECTIVITY
|
|
WLAN + Bluetooth
|
Wi-Fi® 6,
802.11ax 2x2 + BT5.2
|
|
WWAN
|
Non-WWAN
|
|
Ethernet
|
Integrated
100/1000M
|
|
Standard Ports
|
- 3x USB-A (USB 5Gbps / USB
3.2 Gen 1)
- 1x USB-C® (USB 10Gbps / USB
3.2 Gen 2), with Lenovo® PD 140W and DisplayPort™ 1.4
- 1x HDMI® 2.1, up to 8K/60Hz
- 1x Headphone / microphone
combo jack (3.5mm)
- 1x Ethernet (RJ-45)
- 1x Power connector
|
|
Docking
|
Various
docking solutions supported via USB-C®. For more compatible docking
solutions, please visit Docking for LOQ™ 15IRX9
|
|
SECURITY &
PRIVACY
|
|
Security Chip
|
Firmware TPM
2.0 Enabled
|
|
Fingerprint Reader
|
None
|
|
Other Security
|
E-shutter
|
|
SERVICE
|
|
Base Warranty
|
1-year,
Courier or Carry-in
|
|
Included Upgrade
|
None
|
|
ACCESSORIES
|
|
Bundled Accessories
|
None
|
|
CERTIFICATIONS
|
|
Green
Certifications
|
|
|
Other Certifications
|
TÜV
Rheinland® Low Blue Light (Software Solution)
|
|
Mil-Spec Test
|
MIL-STD-810H military
test passed
|
|
MODEL INFORMATION
|
|
Model
|
83DV00UKPS
|
|
Country/Region
|
Pakistan
|
|
TopSeller
|
No
|
|
EAN / UPC / JAN
|
198154973247
|
|
Announce Date
|
2024-07-22
|
|
End of Support
|
2029-12-13
|
