PERFORMANCE |
| Processor | Intel® Core™ i7-13620H, 10C (6P + 4E) / 16T, P-core up to 4.9GHz, E-core up to 3.6GHz, 24MB |
| Graphics | NVIDIA® GeForce MX550 4GB GDDR6 |
| Chipset | Intel® SoC Platform |
| Memory | 1x 16GB SO-DIMM DDR4-3200 |
| Memory Slots | Two DDR4 SO-DIMM slots, dual-channel capable |
| Max Memory | Up to 16GB DDR4-3200 |
| Storage | 1TB SSD M.2 2280 PCIe® 4.0x4 NVMe® |
| Optane Memory | None |
| Storage Support | Up to two drives, 1x 2.5" HDD + 1x M.2 SSD
• 2.5" HDD up to 1TB
• M.2 SSD up to 1TB |
| Card Reader | None |
| Optical | 9.0mm DVD±RW |
| Audio Chip | High Definition (HD) Audio, Realtek® ALC256 codec |
| Speakers | 3Wx2 |
| Camera | HD 720p |
| Microphone | 2x, Array |
| Power Supply | 135W 90% Adapter |
DESIGN |
| Display | 23.8" FHD (1920x1080) IPS 250nits Anti-glare, Touch |
| Touchscreen | 10-point Multi-touch |
| Keyboard | Calliope Wireless Keyboard, White, Arabic |
| Mouse | Calliope Wireless Mouse, White |
| Expansion Slots | Two M.2 slots (one for WLAN, one for SSD) |
| Case Color | White |
| Stand | AIO Stand |
| Pen | No support |
| Form Factor | AIO (23.8 inches) |
| Dimensions (WxDxH) | 541.2 x 185.34 x 433.96 mm (21.3 x 7.29 x 17.08 inches) |
| Weight | 7.03 kg (15.49 lbs) |
CONNECTIVITY |
| Ethernet | Integrated 100/1000M |
| WLAN + Bluetooth | Wi-Fi® 6, 802.11ax 2x2 + BT5.2 |
| Rear Ports | - 2x USB 2.0
- 2x USB 3.2 Gen 2
- 1x HDMI® 1.4
- 1x Ethernet (RJ-45)
- 1x power connector
|
SECURITY & PRIVACY |
| Security Chip | Firmware TPM 2.0 integrated in SoC |
| Physical Locks | No physical locks |
| SERVICE |
| Base Warranty | 1-year, Courier or Carry-in |
| Included Upgrade | None |
CERTIFICATIONS |
| Green Certifications | - ErP Lot 3 and Lot 7
- RoHS compliant
|
SOFTWARE |
| Operating System | None |
| Bundled Software | None |
